锤式破碎机是由锤式破碎机箱体、转子、锤头、反击衬板、筛板等组成。主要用于在水泥，化工，电力，冶金等工业部门破碎中等硬度的物料。

锤式破碎机由上壳体、下壳体、传动部件、筛板部件等组成。

锤式破碎机适用于破碎抗压强度180MPa以下的石灰石、煤矸石、石膏、页岩等各类中硬脆性物料的粗、中、细碎作业。锤式破碎机是直接将最大粒度为600-1800毫米的物料破碎至25或25毫米以下的一段破碎用破碎机。

锤式破碎机适用于在水泥、化工、电力、冶金等工业部门破碎中等硬度的物料，如石灰石、炉渣、焦碳、煤等物料的中碎和细碎作业。单段锤式破碎机为重锤式破碎机，又叫复合锤式破碎机，主要用于石灰石的破碎作业，大型单段锤式破碎机可以将1米直径的石灰岩直接破碎到20mm左右，具有强大的破碎能力。单段锤式破碎机在水泥行业具有大量的应用。

锤式破碎机主要是靠冲击能来完成破碎物料作业的。锤式破碎机工作时，电机带动转子作高速旋转，物料均匀的进入破碎机腔中，高速回转的锤头冲击、剪切撕裂物料致物料被破碎，同时，物料自身的重力作用使物料从高速旋转的锤头冲向架体内挡板、筛条，在转子下部，设有筛板、粉碎物料中小于筛孔尺寸的粒级通过筛板排出，大于筛孔尺寸的物料阻留在筛板上继续受到锤子的打击和研磨，直到破碎至所需出料粒度最后通过筛板排出机外。

Hammer crusher, Hammer crusher price, Crushing equipment product library - Henan Ruilang Machinery

A hammer crusher is composed of a hammer crusher housing, rotor, hammer head, impact lining plate, sieve plate, etc. Mainly used for crushing medium hardness materials in industrial sectors such as cement, chemical, power, metallurgy, etc.

The hammer crusher consists of an upper shell, a lower shell, transmission components, sieve plate components, etc.

The hammer crusher is suitable for crushing various types of medium hard and brittle materials such as limestone, coal gangue, gypsum, shale, etc. with compressive strength below 180MPa in coarse, medium, and fine crushing operations. A hammer crusher is a crushing machine used to directly crush materials with a maximum particle size of 600-1800 millimeters to 25 or less millimeters.

Hammer crushers are suitable for crushing medium hardness materials such as limestone, slag, coke, coal, etc. in industrial sectors such as cement, chemical, power, metallurgy, etc. The single-stage hammer crusher is a heavy hammer crusher, also known as a composite hammer crusher, mainly used for limestone crushing operations. Large single-stage hammer crushers can directly crush limestone with a diameter of 1 meter to about 20mm, with strong crushing capacity. Single stage hammer crushers have a wide range of applications in the cement industry.

Hammer crushers mainly rely on impact energy to complete material crushing operations. When the hammer crusher is in operation, the motor drives the rotor to rotate at high speed, and the material uniformly enters the crusher chamber. The high-speed rotating hammer head impacts, shears and tears the material, causing it to be crushed. At the same time, the gravity of the material itself causes the material to rush from the high-speed rotating hammer head to the baffle and screen strip inside the frame. At the lower part of the rotor, there is a sieve plate, and the particles smaller than the sieve hole size in the crushed material are discharged through the sieve plate. The materials larger than the sieve hole size are retained on the sieve plate and continue to be hit and ground by the hammer until they are crushed to the required discharge particle size and finally discharged outside the machine through the sieve plate.
